Industrial Mobile Energy Storage System GMB-5000
- 5 kWh
- 6200 W Output
- Wheeled Trolley
- IP54
Send us your load list and we size it.
Wheeled 5 kWh industrial mobile energy storage system with a 6200 W inverter, 6000 W of PV input and industrial 32 A sockets. Built for construction sites, workshops and disaster response — roll it to the work front and plug in without trenching a supply.
Best for: Construction sites and disaster response with no supply to trench to
Key Specifications
Battery Parameters
| Battery Type | LiFePO4 3.2 V / 314 Ah |
|---|---|
| Battery Voltage Range | 40 – 60 Vdc |
| Rated Energy | 5120 Wh |
| Maximum Charging / Output Current | 200 / 200 A |
| Rated Charging Power | 4000 W |
| Rated Discharging Power | 6200 W |
Operational Parameters
| PV Maximum Input Power | 6000 W |
|---|---|
| MPPT Operating Voltage Range | 120 – 450 Vdc |
| PV Maximum Open-Circuit Voltage | 500 Vdc |
| AC Input Voltage Range | 90 – 280 Vac (APL) / 170 – 280 Vac (UPS) |
| AC Rated / Maximum Output Power | 6200 W |
| Rated Output Voltage | 200 – 240 Vac (configurable) |
| Rated Operating Frequency | 50 / 60 Hz ± 2% |
| Maximum Output Current | 27 A |
| Transfer Time | 10 ms (typical) |
| Maximum Efficiency | >95% |
System Parameters
| Output Sockets | Industrial angled 32 A, H2519 32 A, AC × 3 (2000 W Max) |
|---|---|
| Input Ports | Industrial reverse plug 32 A, PV XT90 22 A, AC C14 10 A |
| Operating Temperature | -15 ~ 55 ℃ |
| Ingress Protection | IP54 |
| Cycle Life | 6000 times, 0.5C, 90% DOD (25 ℃) |
| Dimension (L×W×H) | 642 × 582 × 445 mm |
| Weight | 70 kg |
When to Choose This
Power that follows the work. A wheeled IP54 unit with industrial sockets, for sites where trenching a cable costs more than the job.
Choose GMB-5000 when:
- The work moves - construction stages, field crews, service vans
- There is no supply to trench to - disaster response, temporary sites
- You need 230 V tools plus solar input at 6000 W in one box
- Setup must take minutes and need no permit
Choose something else when:
| Need | Choose | Why |
|---|---|---|
| Under 2 kW, carried by hand | GPP-1000 / GPP-2000 | 10.5-18.5 kg |
| 50 kW and above, three-phase, days of autonomy | GCB-E100 / containerized ESS | needs a truck |
Run Time
6200 W from 5120 Wh is about 50 minutes at full load, or roughly 8 hours at 600 W. With 6000 W of PV connected, daytime load runs on solar and the pack stays charged. 200 A charge and discharge, 10 ms transfer, 32 A industrial sockets, IP54, 70 kg.
Where It Fits
- Construction stages and field crews that move every few days
- Disaster response and temporary sites with no supply to trench to
- Workshops that need 230 V tools plus solar input in one box
- Jobs where setup has to take minutes and need no permit
Compatible Equipment
230 V industrial sockets, 6000 W of PV input, and a mains or generator recharge.
